Marten® 16a PCE Plug to Neutrik PowerCON TRUE1 NAC3FX-W-TOP 1.5mm HO7RN-F Cable

£13.36 – £19.41

Clear
SKU: N/A Categories: , Tags: , , , , , , , , ,

Description

230v 16a Blue Plug
013-6 PCE 16a Blue 230v 2P+E IP44
Shark Plug IP44 Splashproof
with Screw Terminals
Housing Material: PA6
Cantacts: Brass
230v 16a Black Plug
013-6x PCE 16a Black 230v 2P+E IP44
Shark Plug IP44 Splashproof
with Screw Terminals
Housing Material: PA6
Cantacts: Brass

1.5mm 3 Core HO7RN-F Rubber

Application: Designed primarily as a trailing cable for use in the supply of power for portable or mobile tools and equipment
Suitable to operate under light stress in dry or damp conditions.
Current Rating: 23 Amps

Neutrik PowerCON True1 Mains Cable Connector Male NAC3FX-W-TOP

NAC3FX-W-TOP
Locking Female cable connector, screw terminals

The powerCON TRUE1 TOP is a locking 16 A true mains connector for outdoor applications. It replaces appliance couplers wherever a very rugged solution in combination with a locking device is needed in order to guarantee a safe power connection.

The powerCON TRUE1 TOP is a connector with breaking capacity (CBC), i.e. it can be connected or disconnected under load or live.

Features & Benefits

  • Heavy duty sealed power connector for harsh and demanding environment
  • Outdoor protection according to IP65 and UL50E enclosure type 4 (in mated condition)
  • Uses high impact UV-resistant materials
  • True mains connector with breaking capacity (CBC)
  • Lockable 16 A single phase connector (USA: 20 A)
  • Easy and reliable twist lock system
  • Extremely robust and reliable
  • Unique Neutrik cable retention
  • ENEC certified according to IEC 60320
  • UL498 certified

Additional information

Brand

Marten®
Cable

Titanex HO7-RNF Rubber
Cable Size

1.5mm²
Connector A

PCE 213-6 32a Blue 230v 2P+E IP44
Connector B

Neutrik True1 NAC3FX-W
